Product Details
＋
MS Power MSD Series Stud Mount Rectifier Diode, M16 x 1.5P Anode Stud
Features
- Full blocking capability over wide temperature range
- Hermetic metal case with glass insulator
- Threaded stud
Applications
- Power Supplies
- Uncontrolled Rectifiers
- Oil Cooled Circuits
- Battery Chargers
Specification
| MS Power Part Number | MSD240R16MB |
| Vrrm | 1600V |
| Diode Configuration | Anode Stud |
| IF(av) @ 100 Deg C | 320 Amp |
| IF(av) @ 125 Deg C | 240 Amp |
| Itsm | 6 kA |
| VF(to) | 0.85V |
| Tj(max) | 180°C |
| rF | 0.6mΩ |
| Termination Style (Tail) | 8.3mm Round Lug |
| Termination Style (Stud) | M16 x 1.5P |
| Tail Length to Stud | 200mm |
| R th(j-c) | 0.19°C/W |
| R th(c-h) | 0.03°C/W |
| Weight | 250g |
| Mounting Torque | 26 Nm |
| Factory Pack Qty | 8 |
| Country Of Origin | China |
| MS Power Headquarters | Germany |
