Product Details
＋
A2A-260-12X, Stud Rectifier Diode 260Amp, 1200V, 3/4" UNF 2A, Anode stud
Features
- Full blocking capability over wide temperature range
- Hermetic metal case with glass insulator
- Threaded stud
Applications
- Power Supplies
- Uncontrolled Rectifiers
- Oil Cooled Circuits
- Battery Chargers
Specification
| AEGIS Part Number | A2A-260-12X |
| Vrrm | 1200V |
| Diode Configuration | Anode Stud |
| IF(av) @ 100 Deg C | 320 Amp |
| IF(av) @ 125 Deg C | 260 Amp |
| Itsm | 5.046 kA |
| VF(to) | 0.82V |
| Tj(max) | 180°C |
| rF | 0.45mΩ |
| Termination Style (Tail) | 8.3mm Round Lug |
| Termination Style (Stud) | 3/4" 16 UNF 2A |
| Tail Length to Stud | 170mm |
| R th(j-c) | 0.120°C/W |
| R th(c-h) | 0.03°C/W |
| Weight | 250g |
| Mounting Torque | 26 Nm |
| Factory Pack Qty | 8 |
| Country Of Origin | China |
| AEGIS Headquarters | Brazil |
